KP45A

As a hydraulic power, this lifting hydraulic gear pump is mainly adopted in the hydraulic system of dump truck. Being equipped with operating valve connecting with inside of pump body, so that the lifting and dropping of funnel can be controlled by o

Collect
  • Product Introduction

As a hydraulic power, this lifting hydraulic gear pump is mainly adopted in the hydraulic system of dump truck. Being equipped with operating valve connecting with inside of pump body, so that the lifting and dropping of funnel can be controlled by operating rod.





MODEL Theoretical displacement
ml/r 		pressure
Mpa 		Rated revolution
rpm 		Max. testing pressure
Mpa 		Max. revolution
rpm 		G.W. of oil pump
kg
KP45A 45 7 800 21 1800 13
